Page #715 background image
Parameter Details
12
12.11 T: AUTOTUNING
SIEPCYEUOQ2V01A Q2V Technical Manual 715
12.11 T: AUTOTUNING
Numbers identifying the T parameters are displayed when an LED keypad is used. The names of the parameters
are displayed on the LCD screen of the LCD keypad. Set the following.
Induction Motor Auto-Tuning
PM Motor Auto-Tuning
ASR and Inertia Tuning
T0: TUNE MODE
T0-00: Tune Mode Selection
When your control method supports Control Tuning, set T0-00 first. Then, set T1-00 [Mot1/Mot2 Selection] to
select the motor you will tune. Then, set the tuning mode in T2-01 [PM AutoTune Mode Select] or T3-00 [Control
Loop Tune Selection].
No.
(Hex.)
Name Description
Default
(Range)
T0-00
(1197)
Tune Mode Selection
Sets the type of Auto-Tuning.
0
(0, 1)
0 : Motor Parameter Tuning
1 : Control Tuning
Note:
The available tuning modes are different for different control methods.
T1: INDUCTION MOTOR
T1 parameters set the Auto-Tuning input data for induction motor tuning.
Note:
The base frequency of drive dedicated motors and special motors for use with vector control may be lower than the base frequency of
general-purpose motors, which is 50 Hz or 60 Hz. In such cases, this lower frequency is used as the value for E1-06 [Base Frequency]
and E1-04 [Max Output Frequency] after Auto-Tuning completes. If the maximum output frequency is too low and causes problems,
change the setting of E1-04 after Auto-Tuning completes.
The following induction motor parameters are set automatically.
[E1: V/F PARAMETER MOTOR 1]
[E2: MOTOR 1 PARAMETERS]
[E3: V/F PARAMETER MOTOR 2]
[E4: MOTOR 2 PARAMETERS]
T1-00: Mot1/Mot2 Selection
No.
(Hex.)
Name Description
Default
(Range)
T1-00
(0700)
Mot1/Mot2 Selection
Sets which motor to tune when motor 1/2 switching is enabled.
1
(1, 2)
Note:
Set H1-xx = 61 [Motor 2 Select] to enable this parameter. When H1-xx 61 the keypad will not show this parameter.
1 : Motor 1 (sets E1-xx, E2-xx)
Auto-Tuning automatically sets parameters E1-xx and E2-xx for motor 1.
2 : Motor 2 (sets E3-xx, E4-xx)
Auto-Tuning automatically sets parameters E3-xx and E4-xx for motor 2. Make sure that you connect motor 2 to
the drive for Auto-Tuning.
T1-01: Auto-tuning Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
T1-01
(0701)
Auto-tuning Mode
Selection
Sets the type of Auto-Tuning.
Determined by A1-02
(Determined by A1-02)
