Page #335 background imageLoading...
Page #335 background image
Parameter List
11
11.7 E: MOTOR
SIEPCYEUOQ2V01A Q2V Technical Manual 335
11.7 E: MOTOR
E1: V/F PARAMETER MOTOR 1
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E1-01
(0300)
Input AC Supply Voltage
Sets the drive input voltage.
NOTICE: Set parameter E1-01 to align with the drive input
voltage (not motor voltage). If this parameter is incorrect, the
protective functions of the drive will not operate correctly and it
can cause damage to the drive.
200 V Class: 230 V, 400
V: 400 V
(200 V Class: 155 to 255
V, 400 V Class: 310 to
510 V)
525
E1-03
(0302)
V/f Pattern Selection
Sets the V/f pattern for the drive and motor. You can use one of the preset patterns or
you can make a custom pattern.
0 : CT_50-50Hzmax
1 : CT_60-60Hzmax
2 : CT_50-60Hzmax
3 : CT_60-72Hzmax
4 : VT_50-35HzmidV
5 : VT_50-50HzmidV
6 : VT_60-35HzmidV
7 : VT_60-50HzmidV
8 : HT_50Hz_125 V
9 : HTrq50Hz-165 V
A : HTrq60Hz-125V
B : HT_60Hz-165V
C : HF_60-90Hzmax
D : HF_60-120Hzmax
E : HF_60-180Hzmax
F : Custom
Note:
When A1-02 = 2 [Control Method = OLVector], settings 0 to E are not available.
Set the correct V/f pattern for the application and operation area. An incorrect V/f
pattern can decrease motor torque and increase current from overexcitation.
F
(Determined by A1-02)
525
E1-04
(0303)
Max Output Frequency
Sets the maximum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02
and E5-01)
530
E1-05
(0304)
Max Output Voltage
Sets the maximum output voltage for the V/f pattern.
200.0
(200 V Class: 0.0 - 255.0
V, 400 V Class: 0.0 -
510.0 V)
530
E1-06
(0305)
Base Frequency
Sets the base frequency for the V/f pattern.
Determined by A1-02
and E5-01
(0.0 - E1-04)
530
E1-07
(0306)
Mid A Frequency
Sets a middle output frequency for the V/f pattern.
Determined by A1-02
(0.0 - E1-04)
530
E1-08
(0307)
Mid A Voltage
Sets a middle output voltage for the V/f pattern.
Determined by A1-02
C6-01 and o2-04
(200 V Class: 0.0 - 255.0
V,
400 V Class: 0.0 - 510.0
V)
531
E1-09
(0308)
Min Output Frequency
Sets the minimum output frequency for the V/f pattern.
Determined by A1-02
and E5-01
(Determined by A1-02,
E1-04, and E5-01)
531
E1-10
(0309)
Min Output Voltage
Sets the minimum output voltage for the V/f pattern.
Determined by A1-02
(200 V Class: 0.0 to
255.0 V, 400 V Class:
0.0 to 510.0 V)
531
E1-11
(030A)
Expert
Mid B Frequency
Sets a middle output frequency for the V/f pattern.
0.0 Hz
(0.0 - E1-04)
531
