Omron Q2V Series - Yaskawa SSR1 Series IPM Motors (Derated Torque)

Parameter List
11
11.21 Parameters Changed by PM Motor Code Selection
SIEPCYEUOQ2V01A Q2V Technical Manual 423
No. Name Unit Motor Code (setting value of E5-01)
E1-09 Min Output Frequency Hz
18.0 18.0 18.0
L3-24 Acc@Rated Torque s
0.100 0.100 0.100
n5-02 Mot Inertia Acceleration Time s
0.100 0.100 0.100
n8-49 Heavy Load Id Current %
0.0 0.0 0.0
◆ Yaskawa SSR1 Series IPM Motors (Derated Torque)
Table 11.9 SSR1 Series Motor Code Setting for Specification of 200 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 1202 1203 1205 1206 1208 120A
Voltage Class V 200 200 200 200 200 200
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03 PM Mot Rated Current (FLA) A 1.77 3.13 5.73 8.44 13.96 20.63
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 8.233 2.284 1.470 0.827 0.455 0.246
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 54.84 23.02 17.22 8.61 7.20 4.86
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 64.10 29.89 20.41 13.50 10.02 7.43
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 223.7 220.3 240.8 238.0 238.7 239.6
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Acc@Rated Torque s 0.092 0.076 0.051 0.066 0.075 0.083
n5-02
Mot Inertia Acceleration
Time
s 0.092 0.076 0.051 0.066 0.075 0.083
n8-49 Heavy Load Id Current % -7.6 -11.5 -9.1 -19.0 -18.7 -23.4
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.10 SSR1 Series Motor Code Setting for Specification of 200 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 120B 120D 120E 120F 1210
Voltage Class V 200 200 200 200 200
Capacity kW 7.5 11 15 18.5 22
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 7.5 11.0 15.00 18.50 22.00
E5-03 PM Mot Rated Current (FLA) A 28.13 41.4 55.4 68.2 80.6
E5-04 PM Mot Pole Count - 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 0.198 0.094 0.066 0.051 0.037
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 4.15 3.40 2.45 2.18 1.71
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 5.91 3.91 3.11 2.55 2.05
E5-09
PM BackEMF Vpeak (mV/(rad/
s))
mVs/rad 258.2 239.3 248.1 253.6 250.0
