Omron Q2V Series User Manual

11.21 Parameters Changed by PM Motor Code Selection
424 SIEPCYEUOQ2V01A Q2V Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
E5-24
PM BackEMF L-L Vrms (mV/
rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Acc@Rated Torque s 0.077 0.084 0.102 0.101 0.098
n5-02 Mot Inertia Acceleration Time s 0.077 0.084 0.102 0.101 0.098
n8-49 Heavy Load Id Current % -18.5 -10.9 -16.5 -11.3 -12.8
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.11 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 1232 1233 1235 1236 1238 123A
Voltage Class V 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03 PM Mot Rated Current (FLA) A 0.89 1.56 2.81 4.27 7.08 10.31
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 25.370 9.136 6.010 3.297 1.798 0.982
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 169.00 92.08 67.71 34.40 32.93 22.7
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 197.50 119.56 81.71 54.00 37.70 26.80
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 392.6 440.6 478.3 466.3 478.8 478.1
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Acc@Rated Torque s 0.092 0.076 0.051 0.066 0.075 0.083
n5-02
Mot Inertia Acceleration
Time
s 0.092 0.076 0.051 0.066 0.075 0.083
n8-49 Heavy Load Id Current % -8.6 -11.5 -10.3 -19.8 -8.5 -11.0
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.12 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 123B 123D 123E 123F 1240 1242
Voltage Class V 400 400 400 400 400 400
Capacity kW 7.5 11 15 18.5 22 30
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 7.5 11.0 15 18.50 22.00 30.00
E5-03 PM Mot Rated Current (FLA) A 13.65 20.7 27.5 33.4 39.8 52.0
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 0.786 0.349 0.272 0.207 0.148 0.235
