11.11 n: SPECIAL
SIEPCYEUOQ2V01A Q2V Technical Manual 375
11.11 n: SPECIAL
◆ n1: HUNTING PREVENTION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n1-01
(0580)
HuntPrev Selection
Sets the function to prevent hunting.
Note:
When you replace a V1000-series drive with a Q2V drive, set n1-01 = 1 [HuntPrev
Selection = Enabled].
0 : Disabled
1 : Enabled
2 : Enabled (High Carrier)
0
( 0 to 2 )
675
n1-02
(0581)
Expert
HuntPrev Gain Setting
Sets the performance of the hunting prevention function. Usually it is not necessary to
change this parameter.
1.00
(0.00 - 2.50)
675
n1-03
(0582)
Expert
HuntPrev Time Constant
Sets the primary delay time constant of the hunting prevention function. Usually it is
not necessary to change this parameter.
Determined by o2-04
(0 - 500 ms)
675
n1-05
(0530)
Expert
HuntPrev Gain Reverse
Mode
Sets the performance of the hunting prevention function. This parameter adjusts
Reverse run. Usually it is not necessary to change this parameter.
0.00
(0.00 - 2.50)
675
n1-13
(1B59)
Expert
DCBus Stab.Control
Sets the oscillation suppression function for the DC bus voltage.
0 : Disabled
1 : Enabled
0
(0, 1)
676
n1-14
(1B5A)
Expert
DCBus Stab Time
Adjusts the responsiveness of the oscillation suppression function for the DC bus
voltage. Set n1-13 = 1 [DCBus Stab.Control = Enabled] to enable this parameter.
100.0 ms
(50.0 - 500.0 ms)
676
◆ n2: AFR - AUTO FREQ REGULATION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n2-01
(0584)
AFR Gain
Sets the gain of the AFR function as a magnification value. Usually it is not necessary
to change this setting.
1.00
(0.00 - 10.00)
676
n2-02
(0585)
AFR Time 1
Sets the time constant that sets the rate of change for the AFR function. Usually it is not
necessary to change this setting.
50 ms
(0 - 2000 ms)
676
n2-03
(0586)
AFR Time 2
Sets the time constant that sets the speed difference of the AFR function. Use this
parameter for speed searches or regeneration. Usually it is not necessary to change this
setting.
750 ms
(0 - 2000 ms)
677
◆ n3: HIGHSLIP/OVEREXCITATION BRAKE
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n3-01
(0588)
Expert
HSB Dec Freq Width
Sets the amount by which the output frequency is to be lowered during high-slip
braking, as a percentage of E1-04 [Max Output Frequency], which represents the 100%
value.
5%
(1 - 20%)
678
n3-02
(0589)
Expert
HSB CurrLim Level
Sets the maximum current output during high-slip braking as a percentage, where E2-01
[Mot Rated Current (FLA)] is 100%. Also set the current suppression to prevent
exceeding drive overload tolerance.
Note:
The upper limit to the setting range changes when the setting for C6-01 [ND/HD
Duty Selection] changes.
• 150% when C6-01 = 0 [HD Rating]
• 120% when C6-01 = 1 [ND Rating]
Determined by C6-01
and L8-38
(0 - 150%)
679
n3-03
(058A)
Expert
HSB DwellTime@Stop
Sets the dwell time, a length of time when high-slip braking is ending and during which
the motor speed decreases and runs at a stable speed. For a set length of time, the drive
will hold the actual output frequency at the minimum output frequency set in E1-09.
1.0 s
(0.0 - 10.0 s)
679
