Omron Q2V Series - IP20;UL Open Type (Models 2030 to 2082, 4018 to 4060)

Specifications
10
10.9 Drive Exterior and Mounting Dimensions
SIEPCYEUOQ2V01A Q2V Technical Manual 309
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4005
108
(4.25)
128
(5.04)
199
(7.83)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4007
108
(4.25)
128
(5.04)
199
(7.83)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4009
108
(4.25)
128
(5.04)
199
(7.83)
96
(3.78)
6
(0.24)
118
(4.65)
5
(0.20)
56.5
(2.22)
5
(0.20)
M5
1.9
(4.2)
4012
140
(5.51)
128
(5.04)
193
(7.60)
128
(5.04)
6
(0.24)
118
(4.65)
5
(0.20)
65
(2.56)
5
(0.20)
M5
2.6
(5.7)
◆ IP20/UL Open Type (Models 2030 to 2082, 4018 to 4060)
Figure 10.4 Exterior and Mounting Dimensions
Table 10.32 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2030
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
2042
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
4.1
(9.0)
2056
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
6.0
(13.2)
2070
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
8.5
(18.7)
2082
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
9.0
(19.9)
Table 10.33 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4018
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4023
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4031
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
