11.6 d: REFERENCE
332 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d1-13
(028E)
RUN
Reference 13
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
When A1-02 = 6 [Control Method = PM AOLVector], the default setting is o1-03 =
1 [0.01% (100%=E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
513
d1-14
(028F)
RUN
Reference 14
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
When A1-02 = 6 [Control Method = PM AOLVector], the default setting is o1-03 =
1 [0.01% (100%=E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
513
d1-15
(0290)
RUN
Reference 15
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
When A1-02 = 6 [Control Method = PM AOLVector], the default setting is o1-03 =
1 [0.01% (100%=E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
513
d1-16
(0291)
RUN
Reference 16
Sets the frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Note:
When A1-02 = 6 [Control Method = PM AOLVector], the default setting is o1-03 =
1 [0.01% (100%=E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
513
d1-17
(0292)
RUN
Jog Reference
Sets the Jog frequency reference in the units from o1-03 [FrqDisplay Unit Selection].
Set H1-xx = 6 [MFDI Function Select = Jog Reference] to use the Jog frequency
reference.
Note:
When A1-02 = 6 [Control Method = PM AOLVector], the default setting is o1-03 =
1 [0.01% (100%=E1-04)].
6.00 Hz
(0.00 - 590.00 Hz)
513
◆ d2: REFERENCE LIMITS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d2-01
(0289)
FRef Upper Limit
Sets maximum limit for all frequency references. The maximum output frequency is
100%.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
100.0%
(0.0 - 110.0%)
514
d2-02
(028A)
FRef Lower Limit
Sets minimum limit for all frequency references. The maximum output frequency is
100%.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(0.0 - 110.0%)
514
d2-03
(0293)
Analog FRef Lower
Limit
Sets the lower limit for the master frequency reference (the first frequency of the multi-
step speed reference) as a percentage. The maximum output frequency is 100%.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(0.0 - 110.0%)
514
◆ d3: JUMP FREQUENCY
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d3-01
(0294)
Jump Frequency 1
Sets the median value of the frequency band that the drive will avoid.
0.0 Hz
(Determined by A1-02)
515
d3-02
(0295)
Jump Frequency 2
Sets the median value of the frequency band that the drive will avoid.
0.0 Hz
(Determined by A1-02)
515
