Omron Q2V Series User Manual

Parameter List
11
11.20 Defaults by Drive Model and Duty Rating ND/HD
SIEPCYEUOQ2V01A Q2V Technical Manual 413
No.
*1
Name Unit Default
- Drive Model - 2070 2082
C6-01
ND/HD Duty
Selection
-
HD ND HD ND
0 1 0 1
o2-04 Drive KVA Selection Hex. 6E 6F
E2-11
(E4-11, E5-02)
Motor Rated Power
(kW)
kW 15 18.5 18.5 22
C6-02
Carrier Frequency
Selection
- 3 7 3 7
E2-01
(E4-01)
Mot Rated Current
(FLA)
A 53 65.8 65.8 77.2
E2-02
(E4-02)
Mot Rated Slip Hz 1.6 1.67 1.67 1.7
E2-03
(E4-03)
Mot No-Load Current A 15.2 15.7 15.7 18.5
E2-05
(E4-05)
Motor L-L Resistance Ω 0.138 0.101 0.101 0.079
E2-06
(E4-06)
Motor Leak Inductance % 17.2 15.7 20.1 19.5
E2-10
(E4-10)
Motor Iron Loss W 272 505 505 538
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power Loss
s 2 2 2 2
L2-03 Min Baseblck Time s 1 1 1 1
L2-04
Powloss Ramp
Time@recovery
s 0.6 0.6 0.6 0.6
L2-05
UV Detection Lvl
(Uv1)
- 190 190 190 190
L3-02 StallP Level@Accel % 150 120 150 120
L3-06 StallP Level@Run % 150 120 150 120
L3-24 Acc@Rated Torque s 0.244 0.317 0.317 0.355
L8-02 Overheat Alm Level °C 120 120 135 135
L8-09 Ground Fault Selection - 1 1 1 1
n1-03
HuntPrev Time
Constant
ms 10 10 10 10
n3-02
HSB CurrLim Level
% 150 120 150 120
n5-02
Mot Inertia
Acceleration Time
s 0.244 0.317 0.317 0.355
*1 Parameters within parentheses are for motor 2.
◆ Single-Phase 200 V Class
No.
*1
Name Unit Default
- Drive Model - B001 B002 B004 B006
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 30 31 32 33
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1
b3-04
SpSrch V/F
Gain
% 100 100 100 100 100 100 100 100
b3-06
Speed Curr
Lev1 for
Estimation
- 1 1 1 1 1 1 0.5 0.5
