11.20 Defaults by Drive Model and Duty Rating ND/HD
412 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
*1
Name Unit Default
- Drive Model - 2021 2030 2042 2056
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 68 6A 6B 6D
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 3.7 5.5 5.5 7.5 7.5 11 11 15
E2-05
(E4-05)
Motor L-L
Resistance
Ω 0.771 0.399 0.399 0.288 0.288 0.23 0.23 0.138
E2-06
(E4-06)
Motor Leak
Inductance
% 19.6 18.2 18.2 15.5 15.5 19.5 19.5 17.2
E2-10
(E4-10)
Motor Iron
Loss
W 112 172 172 262 262 245 245 272
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 1 1 1 1 1 1 2 2
L2-03
Min Baseblck
Time
s 0.6 0.7 0.7 0.8 0.8 0.9 0.9 1
L2-04
Powloss
Ramp
Time@recov
ery
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.6
L2-05
UV Detection
Lvl (Uv1)
- 190 190 190 190 190 190 190 190
L3-02
StallP
Level@Accel
% 150 120 150 120 150 120 150 120
L3-06
StallP
Level@Run
% 150 120 150 120 150 120 150 120
L3-24
Acc@Rated
Torque
s 0.154 0.168 0.168 0.175 0.175 0.265 0.265 0.244
L8-02
Overheat Alm
Level
°C 115 115 105 105 115 115 125 125
L8-09
Ground Fault
Selection
- 0 0 1 1 1 1 1 1
n1-03
HuntPrev
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
1 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.154 0.168 0.168 0.175 0.175 0.265 0.265 0.244
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 2070 2082
C6-01
ND/HD Duty
Selection
-
HD ND HD ND
0 1 0 1
o2-04 Drive KVA Selection Hex. 6E 6F
E2-11
(E4-11, E5-02)
Motor Rated Power
(kW)
kW 15 18.5 18.5 22
b3-04 SpSrch V/F Gain % 100 100 100 100
b3-06
Speed Curr Lev1 for
Estimation
- 0.5 0.5 0.5 0.5
b3-08
Speed ACR PGain for
Estimation
- 0.5 0.5 0.5 0.5
b3-26 Dir. Determ. Level - 1000 1000 1000 1000
b8-03 eSave Filter Time s 0.5 0.5 0.5 0.5
b8-04 eSave Coef. Value - 63.13 57.87 57.87 51.79
