11.21 Parameters Changed by PM Motor Code Selection
422 SIEPCYEUOQ2V01A Q2V Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
E1-06 Base Frequency Hz 240 240 240 240
E1-09 Min Output Frequency Hz 12 12 12 12
L3-24 Acc@Rated Torque s 0.137 0.132 0.132 0.122
n5-02
Mot Inertia Acceleration
Time
s 0.137 0.132 0.132 0.122
n8-49 Heavy Load Id Current % 0 0 0 0
◆ Yaskawa SMRD Series SPM Motors
Table 11.7 SMRD Series Motor Code Setting for Specification of 200 V at 1800 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection -
3000 3001 3002
Voltage Class V 200 200 200
Capacity kW 0.1
0.2 0.4
Motor Rotation Speed min
-1
1800 1800 1800
E5-02 PM Mot Rated Power (kW) kW
0.1 0.2 0.4
E5-03 PM Mot Rated Current (FLA) A
0.64 1 1.9
E5-04 PM Mot Pole Count -
6 6 6
E5-05 PM Mot Resistance (Ohms/Phase) Ω
17.200 9.960 3.590
E5-06 PM d-Axis Inductance (mH/Phase) mH
33.20 19.40 11.90
E5-07 PM q-Axis Inductance (mH/Phase) mH
33.20 19.40 11.90
E5-09 PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad
0.0 0.0 0.0
E5-24 PM BackEMF L-L Vrms (mV/rpm) mV/min
-1
59.1 69.8 75.9
E1-04 Max Output Frequency Hz
90.0 90.0 90.0
E1-05 Max Output Voltage V
200.0 200.0 200.0
E1-06 Base Frequency Hz
90.0 90.0 90.0
E1-09 Min Output Frequency Hz
9.0 9.0 9.0
L3-24 Acc@Rated Torque s
0.100 0.100 0.100
n5-02 Mot Inertia Acceleration Time s
0.100 0.100 0.100
n8-49 Heavy Load Id Current %
0.0 0.0 0.0
Table 11.8 SMRD Series Motor Code Setting for Specification of 200 V at 3600 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 3101 3102 3103
Voltage Class V 200 200 200
Capacity kW 0.2 0.4 0.75
Motor Rotation Speed min
-1
3600 3600 3600
E5-02 PM Mot Rated Power (kW) kW
0.20 0.40 0.75
E5-03 PM Mot Rated Current (FLA) A
1.50 2.60 4.20
E5-04 PM Mot Pole Count -
6 6 6
E5-05 PM Mot Resistance (Ohms/Phase) Ω
3.340 1.560 0.541
E5-06 PM d-Axis Inductance (mH/Phase) mH
6.58 3.82 2.24
E5-07 PM q-Axis Inductance (mH/Phase) mH
6.58 3.82 2.24
E5-09
PM BackEMF Vpeak (mV/(rad/
s))
mVs/rad
0.0 0.0 0.0
E5-24
PM BackEMF L-L Vrms (mV/
rpm)
mV/min
-1
26.3 31.0 32.9
E1-04 Max Output Frequency Hz
180.0 180.0 180.0
E1-05 Max Output Voltage V
200.0 200.0 200.0
E1-06 Base Frequency Hz
180.0 180.0 180.0
