11.20 Defaults by Drive Model and Duty Rating ND/HD
414 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
*1
Name Unit Default
- Drive Model - B001 B002 B004 B006
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 30 31 32 33
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1
b3-08
Speed ACR
PGain for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Dir. Determ.
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
eSave Filter
Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
eSave Coef.
Value
- 481.7 356.9 356.9 288.2 288.2 223.7 223.7 196.6
C6-02
Carrier
Frequency
Selection
- 4 7 4 7 4 7 4 7
E2-01
(E4-01)
Mot Rated
Current (FLA)
A 0.6 1.1 1.1 1.9 1.9 3.3 3.3 6.2
E2-02
(E4-02)
Mot Rated
Slip
Hz 2.5 2.6 2.6 2.9 2.9 2.5 2.5 2.6
E2-03
(E4-03)
Mot No-Load
Current
A 0.4 0.8 0.8 1.2 1.2 1.8 1.8 2.8
E2-05
(E4-05)
Motor L-L
Resistance
Ω 35.98 20.56 20.56 9.842 9.842 5.156 5.156 1.997
E2-06
(E4-06)
Motor Leak
Inductance
% 21.6 20.1 20.1 18.2 18.2 13.8 13.8 18.5
E2-10
(E4-10)
Motor Iron
Loss
W 6 11 11 14 14 26 26 53
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2
L2-03
Min Baseblck
Time
s 0.2 0.3 0.2 0.3 0.2 0.3 0.3 0.4
L2-04
Powloss
Ramp
Time@recov
ery
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
UV Detection
Lvl (Uv1)
- 160 160 160 160 160 160 160 160
L3-02
StallP
Level@Accel
% 150 120 150 120 150 120 150 120
L3-06
StallP
Level@Run
% 150 120 150 120 150 120 150 120
L3-24
Acc@Rated
Torque
s 0.178 0.178 0.178 0.178 0.178 0.142 0.142 0.142
L8-02
Overheat Alm
Level
°C 105 105 105 105 115 115 115 115
L8-09
Ground Fault
Selection
- 0 0 0 0 0 0 0 0
n1-03
HuntPrev
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
% 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.178 0.178 0.178 0.142 0.178 0.142 0.142 0.142
*1 Parameters within parentheses are for motor 2.
