Omron Q2V Series User Manual

Parameter List
11
11.20 Defaults by Drive Model and Duty Rating ND/HD
SIEPCYEUOQ2V01A Q2V Technical Manual 415
No.
*1
Name Unit Default
- Drive Model - B010 B012 B018
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 34 35 37
E2-11
(E4-11, E5-02)
Motor Rated
Power (kW)
kW 1.5 2.2 2.2 3.0 3.7 5.5
b3-04 SpSrch V/F Gain % 100 100 100 100 100 100
b3-06
Speed Curr Lev1
for Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed ACR
PGain for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Dir. Determ.
Level
- 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
eSave Coef.
Value
- 169.4 156.8 156.8 136.4 122.9 94.75
C6-02
Carrier Frequency
Selection
- 3 7 3 7 3 7
E2-01
(E4-01)
Mot Rated
Current (FLA)
A 6.2 8.5 8.5 11.4 14 19.6
E2-02
(E4-02)
Mot Rated Slip Hz 2.6 2.9 2.9 2.7 2.73 1.5
E2-03
(E4-03)
Mot No-Load
Current
A 2.8 3 3 3.7 4.5 5.1
E2-05
(E4-05)
Motor L-L
Resistance
Ω 1.997 1.601 1.601 1.034 0.771 0.399
E2-06
(E4-06)
Motor Leak
Inductance
% 18.5 18.4 18.4 19 19.6 18.2
E2-10
(E4-10)
Motor Iron Loss W 53 77 77 91 112 172
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 0.3 0.3 0.5 0.5 1 1
L2-03
Min Baseblck
Time
s 0.4 0.5 0.5 0.5 0.6 0.7
L2-04
Powloss Ramp
Time@recovery
s 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
UV Detection Lvl
(Uv1)
- 160 160 160 160 160 160
L3-02
StallP
Level@Accel
% 150 120 150 120 150 120
L3-06
StallP
Level@Run
% 150 120 150 120 150 120
L3-24
Acc@Rated
Torque
s 0.166 0.145 0.145 0.145 0.154 0.168
L8-02
Overheat Alm
Level
°C 105 105 110 110 115 115
L8-09
Ground Fault
Selection
- 0 0 0 0 0 0
n1-03
HuntPrev Time
Constant
ms 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
% 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.166 0.145 0.145 0.145 0.154 0.168
