Parameter List
11
11.21 Parameters Changed by PM Motor Code Selection
SIEPCYEUOQ2V01A Q2V Technical Manual 425
No. Name Unit Motor Code (setting value of E5-01)
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 16.49 13.17 10.30 8.72 6.81 5.4
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 23.46 15.60 12.77 11.22 8.47 7.26
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 520.0 481.5 498.8 509.5 503.9 561.7
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Acc@Rated Torque s 0.077 0.084 0.102 0.101 0.098 0.130
n5-02
Mot Inertia Acceleration
Time
s 0.077 0.084 0.102 0.101 0.098 0.130
n8-49 Heavy Load Id Current % -18.6 -12.5 -15.5 -17.9 -15.1 -16.8
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.13 SSR1 Series Motor Code Setting for Specification of 200 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 1302 1303 1305 1306 1308 130A
Voltage Class V 200 200 200 200 200 200
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03 PM Mot Rated Current (FLA) A 1.88 3.13 5.63 8.33 14.17 20.63
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 3.190 1.940 1.206 0.665 0.341 0.252
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 32.15 26.12 14.72 12.27 8.27 6.49
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 41.74 34.30 20.15 14.77 9.81 7.74
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 264.3 269.6 284.3 287.1 284.5 298.0
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
*1
Acc@Rated Torque s 0.098 0.071 0.066 0.087 0.085 0.072
n5-02
Mot Inertia Acceleration
Time
s 0.098 0.071 0.066 0.087 0.085 0.072
n8-49 Heavy Load Id Current % -6.6 -10.9 -13.5 -9.0 -9.5 -10.1
*1 The default setting changes when the setting for o2-04 [Drive KVA Selection] changes.
Table 11.14 SSR1 Series Motor Code Setting for Specification of 200 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 130B 130D 130E 130F 1310
Voltage Class V 200 200 200 200 200
Capacity kW 7.5 11 15 18.5 22
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450
E5-02 PM Mot Rated Power (kW) kW 7.5 11.0 15.00 18.50 22.00
