10.3 Model Specifications (Three-Phase 200 V Class)
294 SIEPCYEUOQ2V01A Q2V Technical Manual
Model
2030 2042 2056 2070 2082
Output
Rated Output
Capacity (kVA)
*3
HD 9.5 12.6 17.9 22.9 28.6
ND 11.4 16 21.3 26.7 31.2
Rated Output
Current (A)
HD 25.0 33.0 47.0 60.0 75.0
ND 30 42 56 70 82
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every
10 minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every
10 minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• V/f Control, OLVector, PM OLVector: 590 Hz
• PM AOLVector: 270 Hz
• EZ Vector: 120 Hz
Measures for
Harmonics
DC reactor External options
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3
Category C3 (Conducted emission)
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power (kVA)
HD
11.0 17.0 24.0 31.0 44.0
ND
17.0 24.0 31.0 37.0 52.0
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the
drive output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 220 V.
