Parameter Details
12
12.8 L: PROTECTION
SIEPCYEUOQ2V01A Q2V Technical Manual 659
When you manually clear a fault after the drive triggers protective functions.
When you re-energize the drive.
L5-02: Fault@Reset Select
No.
(Hex.)
Name Description
Default
(Range)
L5-02
(049F)
Fault@Reset Select
Sets the function that sends signals to the MFDO terminal set for Fault [H2-xx = 3] while the
drive is automatically restarting.
1
(1, 2)
1 : Disable Fault Output
2 : Enable Fault Output
L5-04: Interval Reset Time
No.
(Hex.)
Name Description
Default
(Range)
L5-04
(046C)
Interval Reset Time
Sets the time interval between each Auto Restart attempt. This function is enabled when L5-05 =
2 [Reset Method = Use L5-04 Time].
10.0 s
(0.5 - 600.0 s)
L5-05: Reset Method
No.
(Hex.)
Name Description
Default
(Range)
L5-05
(0467)
Reset Method
Sets the count method for the Auto Restart operation.
1
(1, 2)
1 : Continuous
Counts the number of successful fault resets through Auto Restart.
When this value > L5-01, the drive will send a fault signal and fault code to the keypad and the motor will coast to
stop.
2 : Use L5-04 Time
Counts the number of all fault resets (successful and unsuccessful) through Auto Restart. The drive repeats the
Auto Restart process in the intervals set in L5-04 [Interval Reset Time].
When this value > L5-01, the drive will send a fault signal and fault code to the keypad and the motor will coast to
stop.
L5-07: OL1-4 Auto-Reset Select
No.
(Hex.)
Name Description
Default
(Range)
L5-07
(0B2A)
OL1-4 Auto-Reset Select
Use these 4 digits to set the Auto Restart function for oL1 to oL4. From left to right, the digits set
oL1, oL2, oL3, and oL4, in order.
1111
(0000 - 1111)
0000 : Disabled
0001 : Enabled (—/—/—/oL4)
0010 : Enabled (—/—/oL3/—)
0011 : Enabled (—/—/oL3/oL4)
0100 : Enabled (—/oL2/—/—)
0101 : Enabled (—/oL2/—/oL4)
0110 : Enabled (—/oL2/oL3/—)
0111 : Enabled (—/oL2/oL3/oL4)
1000 : Enabled (oL1/—/—/—)
1001 : Enabled (oL1/—/—/oL4)
1010 : Enabled (oL1/—/oL3/—)
1011 : Enabled (oL1/—/oL3/oL4)
1100 : Enabled (oL1/oL2/—/—)
1101 : Enabled (oL1/oL2/—/oL4)
