12.7 H: TERMINALS
594 SIEPCYEUOQ2V01A Q2V Technical Manual
■ H2-41: Mbus 15E0h b1 Output Function
No.
(Hex.)
Name Description
Default
(Range)
H2-41
(0B59)
Mbus 15E0h b1 Output
Function
Sets the MFDO for bit 1 of Modbus register 15E0 (Hex.).
F
(0 - 1FF)
■ H2-42: Mbus 15E0h b2 Output Function
No.
(Hex.)
Name Description
Default
(Range)
H2-42
(0B5A)
Mbus 15E0h b2 Output
Function
Sets the MFDO for bit 2 of Modbus register 15E0 (Hex.).
F
(0 - 1FF)
■ H2-60: NO,NC,CM 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-60
(1B46)
Expert
NO,NC,CM 2nd Function
Sets the second function for terminal NO/NC-CM. Outputs the logical calculation results of the
terminals assigned to functions by H2-01 [NO,NC,CM FuncSelection].
0
(0 - FF)
■ H2-61: NO,NC,CM Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-61
(1B47)
Expert
NO,NC,CM Logic
Operation
Sets the logical operation for the functions set in H2-01 [NO,NC,CM FuncSelection] and H2-60
[NO,NC,CM 2nd Function].
1
(1 - 9)
Refer to Output of Logical Operation Results of MFDO on page 588 for more information about the relation
between parameter settings and logical operations.
■ H2-62: NO,NC,CM Min ON-Time
No.
(Hex.)
Name Description
Default
(Range)
H2-62
(1B48)
Expert
NO,NC,CM Min ON-Time
Sets the minimum ON time that the drive uses to output the logical calculation results from
terminal NO,NC,CM.
0.1 s
(0.0 - 25.0 s)
■ H2-63: DO1 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-63
(1B49)
Expert
DO1 2nd Function
Sets the second function for terminal DO1-O1C. Outputs the logical calculation results of the
terminals assigned to functions by H2-02 [DO1-O1C Func Selection].
o
(0 - FF)
■ H2-64: DO1 Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-64
(1B4A)
Expert
DO1 Logic Operation
Sets the logical operation for the functions set in H2-02 [DO1-O1C Func Selection] and H2-63
[DO1 2nd Function].
1
(1 - 9)
Refer to Output of Logical Operation Results of MFDO on page 588 for more information about the relation
between parameter settings and logical operations.
■ H2-65: DO1 Min ON-Time
No.
(Hex.)
Name Description
Default
(Range)
H2-65
(1B4B)
Expert
DO1 Min ON-Time
Sets the minimum ON time used to output the logical calculation results from terminal DO1-O1C.
0.1 s
(0.0 - 25.0 s)
