Page #305 background imageLoading...
Page #305 background image
Specifications
10
10.8 Drive Models and Drive Watt Loss
SIEPCYEUOQ2V01A Q2V Technical Manual 305
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B010 8 2 34 37 71
B012 11 2 45 48 93
B018 17.6 2 50 72 122
Table 10.21 Drive Watt Loss (HD, Fc = Default Setting)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 0.8 10 9 5 14
B002 1.6 10 12 9 21
B004 3 10 18 16 34
B006 5 10 21 28 49
B010 8 8 35 42 77
B012 11 8 46 55 101
B018 17.6 8 54 98 152
Table 10.22 Drive Watt Loss (ND)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 1.2 2 9 6 15
B002 1.9 2 18 11 29
B004 3.5 2 19 17 36
B006 6.0 2 20 26 46
B010 9.6 2 44 50 94
B012 12.2 2 56 60 116
B018 N/A 2 50 92 142
Three-Phase 400 V Class
Table 10.23 Drive Watt Loss (HD, Fc = 2 kHz)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001 1.2 2 9 7 16
4002 1.8 2 11 10 21
4004 3.4 2 15 21 36
4005 4.8 2 17 29 46
4007 5.6 2 18 33 51
4009 7.3 2 24 45 69
4012 9.2 2 29 60 89
4018 14.8 2 52 126 178
4023 18 2 57 152 209
4031 24 2 73 191 264
4038 31 2 89 256 345
4044 39 2 119 338 457
4060 45 2 128 328 456
Table 10.24 Drive Watt Loss (HD, Fc = Default Setting)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001 1.2 8 10 11 21
4002 1.8 8 12 16 28
4004 3.4 8 17 31 48
