Omron Q2V Series User Manual

10.8 Drive Models and Drive Watt Loss
306 SIEPCYEUOQ2V01A Q2V Technical Manual
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4005 4.8 8 20 42 62
4007 5.6 8 20 49 69
4009 7.3 8 28 65 93
4012 9.2 8 34 85 119
4018 14.8 8 59 166 225
4023 18 8 65 200 265
4031 24 8 84 255 339
4038 31 8 103 338 441
4044 39 8 137 442 579
4060 45 8 149 446 595
Table 10.25 Drive Watt Loss (ND)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001 1.2 2 9 7 16
4002 2.1 2 14 12 26
4004 4.1 2 16 24 40
4005 5.4 2 18 32 50
4007 7.1 2 23 44 67
4009 8.9 2 33 58 91
4012 11.9 2 41 83 124
4018 17.5 2 56 155 211
4023 23.4 2 94 236 330
4031 31 2 109 284 393
4038 38 2 119 341 460
4044 44 2 151 417 568
4060 60 2 200 490 690
