Parameter Details
12
12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 591
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-23: Compare1 Hysteresis
No.
(Hex.)
Name Description
Default
(Range)
H2-23
(1543)
Compare1 Hysteresis
Sets the hysteresis level for comparator 1 as a percentage of the full scale analog output for the
monitor selected in H2-20 [Compare1 Mon.Selection].
0.0%
(0.0 - 10.0%)
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-24: Compare1 On-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-24
(1544)
Compare1 On-Delay Time
Sets the on-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-25: Compare1 Off-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-25
(1545)
Compare1 Off-Delay Time
Sets the off-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-26: Compare2 Mon.Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-26
(1546)
Compare2 Mon.Selection
Sets the monitor number for comparator 2. Set the x-xx part of the Ux-xx [Monitor]. For example,
set H2-26 = 103 to monitor U1-03 [Output Current].
103
(000 - 999)
Note:
• The configurable monitor changes when the control method changes.
• When you use the terminal in through mode, set this parameter to 000 or 031. You can set the terminal output level from the PLC
through Modbus communications or the communication option.
• For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-27: Compare2 Low Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-27
(1547)
Compare2 Low Limit
Sets the lower limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Compare2 Mon.Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
■ H2-28: Compare2 Up Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-28
(1548)
Compare2 Up Limit
Sets the upper limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Compare2 Mon.Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to 3C: Comparator 1 on page 605 and 3D: Comparator 2 on page 605.
