11.9 H: TERMINALS
352 SIEPCYEUOQ2V01A Q2V Technical Manual
Setting Value Function Description Ref.
67 SpdSrch Fmax
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection =
Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same
time.
584
68 SpdSrch Fref
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection =
Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same
time.
584
6A PID Disable
Sets the command to disable PID control when b5-01 = 1 [PID Enable = Enabled].
ON : PID control disabled
OFF : PID control enabled
584
71 PID I Reset
Sets the command to reset and hold the PID control integral to 0 when the terminal is ON.
584
72 PID I Hold
Sets the command to hold the integral value of the PID control while the terminal is activated.
584
75 PID SS Cancel
Sets the PID soft starter function.
ON : No
OFF : Yes
585
76 PID InLv Select
Sets the command to turn the terminal ON and OFF to switch the PID input level (polarity).
585
77 PID SP 1
Set this function and H1-xx = 78 [PID SP 2] together. Sets the function to switch the PID setpoint to b5-58 to b5-
60 [PID Setpoints 2 to 4].
585
78 PID SP 1
Set this function and H1-xx = 77 [PID SP 1] at the same time. Sets the function to switch the PID setpoint to b5-58
to b5-60 [PID Setpoints 2 to 4].
585
7A PID BiDir
Sets operation of the PID Bi-Directional function.
ON : Enabled
OFF : Disabled
585
7B Fault Reset
Sets the command to reset the current fault when the Run command is inactive.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command
before trying to reset a fault.
585
7C Prg Lock
Sets the command to prevent parameter changes when the terminal is OFF.
ON : Programming Lockout
OFF : Parameter Write Prohibit
586
7D Drive OH2
Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal is ON. The alarm does
not have an effect on drive operation.
586
7E Node Setup
Sets the function in CANopen communications to start the Node Setup function to set the drive node address from
the host controller.
586
7F Comms Test
Set the function for the drive to self-test RS-485 serial communications operation.
586
90 - 96 Q2pack DI1 to 7
Sets digital inputs used with Q2pack. Refer to the Q2pack online manual for more information.
586
9F Q2pack Disable
Sets operation of the Q2pack program saved in the drive.
ON : No
OFF : Yes
Note:
Set A1-07 = 2 [Q2pack Enable = With DI] to enable this function.
586
101 to 19F Inverse Input of 1 to 9F Sets the function of the selected MFDI to operate inversely. To select the function, enter “1xx”, where the “xx” is
the function setting value.
Note:
You cannot use inverse input for all functions. Refer to Table 12.38 for more information.
586
