11.9 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 351
Setting Value Function Description Ref.
3E SCBraking NO
Sets operation of Short Circuit Braking (N.O.).
ON : Short Circuit Braking is enabled.
OFF : Normal operation
Note:
When A1-02 = 8 [Control Method = EZ Vector], this function is available only when you use a PM motor.
578
3F SCBraking NC
Sets operation of Short Circuit Braking (N.C.).
ON : Normal operation
OFF : Short Circuit Braking is enabled.
Note:
When A1-02 = 8 [Control Method = EZ Vector], this function is available only when you use a PM motor.
578
40 KEB Thru1 NC
Sets operation of the KEB1 function through the KEB Ride-Thru 1 (N.C.).
ON : Normal operation
OFF : Deceleration during momentary power loss
578
41 KEB Thru1 NO
Sets operation of the KEB1 function through the KEB Ride-Thru 1 (N.O.).
ON : Deceleration during momentary power loss
OFF : Normal operation
579
42 KEB Thru2 NC
Sets operation of the KEB2 function through the KEB Ride-Thru 2 (N.C.).
ON : Normal operation
OFF : Deceleration during momentary power loss
579
43 KEB Thru2 NO
Sets operation of the KEB2 function through the KEB Ride-Thru 2 (N.O.).
ON : Deceleration during momentary power loss
OFF : Normal operation
579
44 Field weakening
Sets the function to send the Field Weakening Level and Field Weakening Frequency Limit commands set in d6-01
[Field Weak Level] and d6-02 [Field Weak FqLimit] when the input terminal is activated.
579
45 ASR Gain Switch
Sets the function to switch the ASR proportional gain set in C5-01 [ASR PGain 1] and C5-03 [ASR PGain 2].
ON : C5-03
OFF : C5-01
579
46 ASR I Reset
Sets the command to reset the integral value and use PI control or P control for the speed control loop.
ON : P control
OFF : PI control
580
60 Timer Fn Input
Sets the command to start the timer function. Use this setting with Timer Output [H2-xx = 39].
580
61 Motor 2 Select
Sets the command for the drive to operate motor 1 or motor 2. Stop the motors before switching.
ON : Operate motor 2
OFF : Operate motor 1
580
62 Up Command
Sets the command to use a push button switch to increase the drive frequency reference. You must also set Setting
63 [Down Command].
ON : Increases the frequency reference.
OFF : Holds the current frequency reference.
580
63 Down Command
Sets the command to use a push button switch to decrease the drive frequency reference. You must also set Setting
62 [Up Command].
ON : Decreases the frequency reference.
OFF : Holds the current frequency reference.
582
65 Up2 Command
Sets the function to increase the frequency reference bias value to accelerate the motor when the terminal is
activated. Set this function and H1-xx = 66 [Dw2 Command] together.
Note:
When you use this function, use d4-08 and d4-09 [Up/Dw2 Bias Upper Limit and Up/Dw2 Bias Lower Limit]
to set the optimal bias limit value.
582
66 Dw2 Command
Sets the function to decrease the frequency reference bias value to decelerate the motor when the terminal is
activated. Set this function and H1-xx = 65 [Up2 Command] at the same time.
Note:
When you use this function, use d4-08 and d4-09 [Up/Dw2 Bias Lower Limit] to set the optimal bias limit
value.
584
