12.7 H: TERMINALS
584 SIEPCYEUOQ2V01A Q2V Technical Manual
■ 66: Dw2 Command
Setting Value Function Description
66 Dw2 Command
Sets the function to decrease the frequency reference bias value to decelerate the motor when the terminal is activated. Set this
function and H1-xx = 65 [Up2 Command] at the same time.
When you activate the terminal set for Up2 Command, the bias will increase. When you activate the terminal set
for Down 2 Command, the bias will decrease. When you activate or deactivate the two commands, the drive will
hold the frequency reference.
Note:
• When using this function, set the optimal bias limit value with d4-08 and d4-09 [Up/Dw2 Bias Upper Limit and Up/Dw2 Bias Lower
Limit].
• Refer to “d4: FREQUENCY UP/DOWN on page 516” for more information.
■ 67: SpdSrch Fmax
Setting Value Function Description
67 SpdSrch Fmax
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection = Disabled].
When the terminal is turned ON for b3-24 = 2 [SpSrch Method Selection = Current Det2], the drive starts speed
search from the maximum output frequency.
Note:
• The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same time.
• Refer to “b3: SPEED SEARCH on page 456” for more information.
■ 68: SpdSrch Fref
Setting Value Function Description
68 SpdSrch Fref
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection = Disabled].
When the terminal is turned ON for b3-24 = 2 [SpSrch Method Selection = Current Det2], the drive starts speed
search from the frequency reference.
Note:
• The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same time.
• Refer to “b3: SPEED SEARCH on page 456” for more information.
■ 6A: PID Disable
Setting Value Function Description
6A PID Disable
Sets the command to disable PID control when b5-01 = 1 [PID Enable = Enabled].
ON : PID control disabled
OFF : PID control enabled
■ 71: PID I Reset
Setting Value Function Description
71 PID I Reset
Sets the command to reset and hold the PID control integral to 0 when the terminal is ON.
Note:
Refer to “b5: PID CONTROL on page 466” for more information.
■ 72: PID I Hold
Setting Value Function Description
72 PID I Hold
Sets the command to hold the integral value of the PID control while the terminal is activated.
When you turn off the input terminal, PID control restarts the integral.
Note:
Refer to “b5: PID CONTROL on page 466” for more information.
