Parameter Details
12
12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 585
■ 75: PID SS Cancel
Setting Value Function Description
75 PID SS Cancel
Sets the PID soft starter function.
ON : No
Disables b5-17 [PID Accel/Decel Time].
OFF : Yes
Enables b5-17 [PID Accel/Decel Time].
Note:
Refer to “b5: PID CONTROL on page 466” for more information.
■ 76: PID InLv Select
Setting Value Function Description
76 PID InLv Select
Sets the command to turn the terminal ON and OFF to switch the PID input level (polarity).
Note:
Refer to “b5: PID CONTROL on page 466” for more information.
■ 77: PID SP 1
Setting Value Function Description
77 PID SP 1
Set this function and H1-xx = 78 [PID SP 2] together. Sets the function to switch the PID setpoint to b5-58 to b5-60 [PID
Setpoints 2 to 4].
Refer to “b5-58 to b5-60: PID Setpoints 2 to 4 on page 479” for more information.
■ 78: PID SP 1
Setting Value Function Description
78 PID SP 1
Set this function and H1-xx = 77 [PID SP 1] at the same time. Sets the function to switch the PID setpoint to b5-58 to b5-60
[PID Setpoints 2 to 4].
Refer to “b5-58 to b5-60: PID Setpoints 2 to 4 on page 479” for more information.
■ 7A: PID BiDir
Setting Value Function Description
7A PID BiDir
Sets operation of the PID Bi-Directional function.
ON : Enabled
OFF : Disabled
■ 7B: Fault Reset
Setting Value Function Description
7B Fault Reset
Sets the command to reset the current fault when the Run command is inactive.
If the drive detects a fault, the drive will activate the fault relay output, turn off the output, and the motor will
coast to stop.
If the drive detects a fault for which you can set the stopping method, apply the appropriate Stopping Method.
Then push (RESET) on the keypad to turn the Run command OFF, or activate the fault reset terminal to reset
the fault.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command before trying to reset a fault.
