12.7 H: TERMINALS
586 SIEPCYEUOQ2V01A Q2V Technical Manual
■ 7C: Prg Lock
Setting Value Function Description
7C Prg Lock
Sets the command to prevent parameter changes when the terminal is OFF.
You can continue to view parameter setting values when the terminal is OFF [Parameters Cannot be Edited].
ON : Program Lockout
OFF : Parameter Write Prohibit
■ 7D: Drive OH2
Setting Value Function Description
7D Drive OH2
Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal is ON. The alarm does not have an
effect on drive operation.
■ 7E: Node Setup
Setting Value Function Description
7E Node Setup
Sets the function in CANopen communications to start the Node Setup function to set the drive node address from the host
controller.
■ 7F: Comms Test
Setting Value Function Description
7F Comms Test
Set the function for the drive to self-test RS-485 serial communications operation.
The Self-Diagnostics function connects the transmission terminal of the control terminal block to the reception
terminal. The function transmits the data that the drive sent to make sure that the drive can communicate correctly.
Note:
Refer to Modbus communications “Self-Diagnostics” for the self-diagnostics procedure.
■ 90 to 96: Q2pack DI1 to 7
Setting Value Function Description
90 - 96 Q2pack DI1 to 7
Sets digital inputs used with Q2pack. Refer to the Q2pack online manual for more information.
Note:
You cannot set values 90 to 96 for inverse output.
■ 9F: Q2pack Disable
Setting Value Function Description
9F Q2pack Disable
Sets operation of the Q2pack program saved in the drive.
Note:
Set A1-07 = 2 [Q2pack Enable = With DI] to use this function.
ON : Disabled
OFF : Enabled
■ 101 to 19F: Inverse Input of 1 to 9F
Setting Value Function Description
101 to 19F Inverse Input of 1 to 9F Sets the function of the selected MFDI to operate inversely. To select the function, enter “1xx”, where the “xx” is the function
setting value.
For example, to use the inverse input of 46 [ASR I Reset], set H1-xx = 146.
Note:
You cannot use inverse input for all functions.
