Parameter List
11
11.16 U: MONITORS
SIEPCYEUOQ2V01A Q2V Technical Manual 401
No.
(Hex.)
Name Description MFAO Signal Level
U6-09
(07C0)
Expert
AdvPhase Compen
Displays the data on forward phase compensation for the calculation results of the amount of
control axis deviation.
Unit: 1 °
10 V: 180 ° (-10 V to +10
V)
U6-10
(07C1)
Expert
ContAxisDeviation
Shows the deviation between the γδ-Axis used for motor control and the dq-Axis.
Unit: 0.1 °
10 V: 180 ° (-10 V to +10
V)
U6-14
(07CB)
Expert
MagPolePos (Obs)
Shows the value of the flux position estimation.
Unit: 0.1 °
10 V: 180 ° (-10 V to +10
V)
U6-17
(07D1)
Expert
Energy Save Coeff
Shows the total time of direction of motor rotation detections for Speed Estimation Speed
Searches. This value adjusts b3-26 [Dir. Determ. Level].
Note:
Upper limit is +32767 and lower limit is -32767.
No signal output available
U6-20
(07D4)
FRef Bias (UpDw2)
Shows the bias value used to adjust the frequency reference.
Unit: 0.1%
10 V: Maximum Frequency
U6-21
(07D5)
Offset Frequency
Shows the total value of d7-01 to d7-03 [Offset Frq 1 to Offset Frq 3] selected with Offset Frq 1
to Offset Frq 3[H1-xx = F to 10].
Unit: 0.1%
10 V: Maximum Frequency
U6-31
(007B)
Trq Detect Monitor
Monitors the torque reference or the output current after applying the filter set to L6-07 [Trq
Detect Filter Time].
Unit: 0.1%
10 V:100%
U6-36
(0720)
Expert
Comm Err n-IO
Shows the number of inter-CPU communication errors. De-energizing the drive sets this number
to 0.
No signal output available
U6-37
(0721)
Expert
Comm Err n-PWM
Shows the number of inter-CPU communication errors. De-energizing the drive sets this number
to 0.
No signal output available
U6-57
(07C4)
PoleDis IdDifVal
Shows the change from the integrated current when finding the polarity.
Unit: 1
Note:
If the change from the integrated current is less than 819, increase n8-84 [Polarity Det
Current]. U6-57 = 8192 is equivalent to the motor rated current.
No signal output available
U6-80 to U6-83
(07B0 - 07B3)
OPT IP ADR1 to 4
Shows the currently available local IP Address.
• U6-80: 1st octet
• U6-81: 2nd octet
• U6-82: 3rd octet
• U6-83: 4th octet
No signal output available
U6-84 to U6-87
(07B4 - 07B7)
Online Subnet 1 to 4
Shows the currently available subnet mask.
• U6-84: 1st octet
• U6-85: 2nd octet
• U6-86: 3rd octet
• U6-87: 4th octet
No signal output available
U6-88 to U6-91
(07B8, 07B9,
07F0, 07F1)
Online Gateway 1 to 4
Shows the currently available gateway address.
• U6-88: 1st octet
• U6-89: 2nd octet
• U6-90: 3rd octet
• U6-91: 4th octet
No signal output available
U6-92
(07F2)
Online Speed
Shows the currently available communications speed.
10: 10 Mbps
100: 100 Mbps
No signal output available
U6-93
(07F3)
Online Duplex
Shows the currently available Duplex setting.
No signal output available
