Parameter Details
12
12.10 o: KEYPAD
SIEPCYEUOQ2V01A Q2V Technical Manual 699
■ o1-40: Home Screen Selection Mode
No.
(Hex.)
Name Description
Default
(Range)
o1-40
(11BD)
RUN
Home Screen Selection
Mode
Sets the monitor display mode for the Home screen. This parameter is only available when using
an LCD keypad.
0
(0 - 3)
0 : Monitors
1 : Manual 1
2 : Manual 2
3 : Manual 3
■ o1-41: 1stMon Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-41
(11C1)
RUN
1stMon Area Selection
Sets the horizontal range used to display the monitor set in o1-24 [Cust.Monitor 1] as a bar graph.
This parameter is only available when using an LCD keypad.
0
(0 - 2)
0 : +/- Area (- o1-42 - o1-42 )
1 : + Area (0 - o1-42 )
2 : - Area (- o1-42 - 0)
■ o1-42: 1stMon Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-42
(11C2)
RUN
1stMon Area Setting
Sets the horizontal axis value used to display the monitor set in o1-24 [Cust.Monitor 1] as a bar
graph. This parameter is only available when using an LCD keypad.
100.0%
(0.0 - 100.0%)
■ o1-43: 2ndMon Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-43
(11C3)
RUN
2ndMon Area Selection
Selects the horizontal range used to display the monitor set in o1-25 [Custom Monitor 2] as a bar
graph. This parameter is only available when using an LCD keypad.
0
(0 - 2)
0 : + - Area (- o1-44 - o1-44)
1 : + Area (0 - o1-44)
2 : - Area (- o1-44 - 0 )
■ o1-44: 2ndMon Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-44
(11C4)
RUN
2ndMon Area Setting
Sets the horizontal axis value used to display the monitor set in o1-25 [Cust.Monitor 2] as a bar
graph. This parameter is only available when using an LCD keypad.
100.0%
(0.0 - 100.0%)
■ o1-45: 3rdMon Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-45
(11C5)
RUN
3rdMon Area Selection
Sets the horizontal range used to display the monitor set in o1-26 [Cust.Monitor 3] as a bar graph.
This parameter is only available when using an LCD keypad.
0
(0 - 2)
0 : + - Area (- o1-46 - o1-46)
1 : + Area (0 - o1-46 )
2 : - Area (- o1-46 - 0 )
