12.10 o: KEYPAD
702 SIEPCYEUOQ2V01A Q2V Technical Manual
■ o2-02: STOP Key Selection of Function
No.
(Hex.)
Name Description
Default
(Setting Range)
o2-02
(0506)
STOP Key Selection of
Function
Sets the function to use on the keypad to stop the drive when the Run command source
for the drive is REMOTE (external) and not assigned to the keypad.
1
(0, 1)
0 : Disabled
1 : Enabled
stays enabled when the Run command source has not been assigned to the keypad.
To start the drive again after you push to stop operation, turn the external Run command OFF and ON
again.
■ o2-03: UserPar Set Default Values
No.
(Hex.)
Name Description
Default
(Range)
o2-03
(0507)
UserPar Set Default Values
Sets the function to keep the settings of changed parameters as user parameter defaults to use
during initialization.
0
(0 - 2)
When you set o2-03 = 1 [Set defaults], the drive saves changed parameter settings as user parameter setting
values in a part of the memory that is isolated from drive parameters.
When you set A1-03 = 1110 [Init Parameters = User / Solution Initialization] to initialize the drive, the drive
resets the internal parameter setting values to those user parameter setting values.
0 : No change
1 : Set defaults
Saves changed parameter setting values as user default settings.
Set o2-03 = 1 then push to save the user parameter setting values. After the drive saves the setting value, o2-
03 automatically resets to 0.
2 : Clear all
Deletes all of the saved user parameter setting values.
Set o2-03 = 2 then push to clear the user parameter setting values. The drive will automatically reset o2-03 to
0. If you delete the user parameter setting values, you cannot set A1-03 = 1110 to initialize parameters.
■ o2-04: Drive KVA Selection
No.
(Hex.)
Name Description
Default
(Setting Range)
o2-04
(0508)
Drive KVA Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
NOTICE: Set o2-04 [Drive KVA Selection] correctly. If you set this parameter incorrectly, it will decrease drive performance,
cause the protection function to operate incorrectly, and cause damage to the drive.
Note:
When the setting value of o2-04 changes, related parameter setting values also change. Refer to Defaults by Drive Model and Duty
Rating ND/HD on page 409 for more information.
These tables list the relation between o2-04 setting values and drive models.
o2-04 Setting Drive Model
30 B001
31 B002
32 B004
33 B006
34 B010
35 B012
o2-04 Setting Drive Model
37 B018
60 2001
61 2002
62 2004
63 2006
64 2008
