Parameter Details
12
12.10 o: KEYPAD
SIEPCYEUOQ2V01A Q2V Technical Manual 703
o2-04 Setting Drive Model
65 2010
66 2012
67 2018
68 2021
91 2030
92 2042
93 2056
94 2070
95 2082
96 4001
97 4002
o2-04 Setting Drive Model
99 4004
6A 4005
6B 4007
6D 4009
6E 4012
6F 4018
9A 4023
9C 4031
9D 4038
9E 4044
9F 4060
■ o2-05: LCD FreqRef Mode@Home Screen
No.
(Hex.)
Name Description
Default
(Setting Range)
o2-05
(0509)
LCD FreqRef
Mode@Home Screen
Sets the function that makes it necessary to push to use the keypad to change the frequency
reference value while in Drive Mode.
0
(0, 1)
0 : Disabled
You must push to use the keypad to change the frequency reference value.
1 : Enabled
The frequency reference changes when you enter it with the keypad. This then changes the output frequency. It is
not necessary to push . The drive keeps the frequency reference for 5 seconds after you use and on
the keypad to change the frequency reference value.
■ o2-06: Keypad Disconnect Detection
No.
(Hex.)
Name Description
Default
(Range)
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable from the drive
or if you damage the cable while the keypad is the Run command source.
0
(0, 1)
This parameter continues to operate if the keypad installed to the drive becomes disconnected.
This parameter is enabled in these conditions:
• When b1-02 = 0 [Run Comm. Sel 1 = Keypad] or b1-16 = 0 [Run Comm. Sel 2 = Keypad]
• In LOCAL Mode
0 : Disabled
The drive continues operation when it detects a keypad disconnection.
1 : Enabled
The drive stops operation, detects oPr [Keypad Connection Fault], and the motor coasts to stop when the drive
detects a keypad disconnection.
■ o2-07: Keypad Dir@Power-Up
No.
(Hex.)
Name Description
Default
(Range)
o2-07
(0527)
Keypad Dir@Power-Up
Sets the direction of motor rotation when the drive is energized and the keypad is the Run
command source.
0
(0, 1)
This parameter is enabled in these conditions:
• When b1-02 = 0 [Run Comm. Sel 1 = Keypad] or b1-16 = 0 [Run Comm. Sel 2 = Keypad]
• In LOCAL Mode
To Next Page
