Parameter Details
12
12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 621
■ H5-02: Mbus BaudRate
No.
(Hex.)
Name Description
Default
(Range)
H5-02
(0426)
Mbus BaudRate
Sets the communications speed for Modbus communications.
4
(1 - 9)
Note:
Restart the drive after changing the parameter setting.
1 : 1200 bps
2 : 2400 bps
3 : 4800 bps
4 : 9600 bps
5 : 19.2 kbps
6 : 38.4 kbps
7 : 57.6 kbps
8 : 76.8 kbps
9 : 115.2 kbps
■ H5-03: Mbus Parity
No.
(Hex.)
Name Description
Default
(Range)
H5-03
(0427)
Mbus Parity
Sets the communications parity used for Modbus communications.
1
(1 - 3)
Note:
Restart the drive after changing the parameter setting.
1 : Even parity
2 : Odd parity
3 : No parity
■ H5-04: Mbus Error Stop
No.
(Hex.)
Name Description
Default
(Range)
H5-04
(0428)
Mbus Error Stop
Sets the motor Stopping Method when the drive detects CE [Modbus Communication Err] issues.
3
(0 - 3)
0 : Ramp->Stop
The drive ramps the motor to stop in the deceleration time. The output terminal set for Fault [H2-01 to H2-03 =
3] activates.
1 : Coast->Stop
The output turns off and the motor coasts to stop. The output terminal set for Fault [H2-01 to H2-03 = 3]
activates.
2 : Fast Stop (C1-09)
The drive stops the motor in the deceleration time set in C1-09 [Fast Stop Time]. The output terminal set for Fault
[H2-01 to H2-03 = 3] activates.
3 : Alarm Only
The keypad shows CE and the drive continues operation. The output terminal set for Alarm [H2-01 to H2-03 = 4]
activates.
■ H5-05: Mbus Fault Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
H5-05
(0429)
Mbus Fault Detection
Selection
Sets the function that detects CE [Modbus Communication Error] issues during Modbus
communications.
1
(0, 1)
