12.5 E: MOTOR
540 SIEPCYEUOQ2V01A Q2V Technical Manual
■ E5-04: PM Mot Pole Count
No.
(Hex.)
Name Description
Default
(Range)
E5-04
(032C)
PM Mot Pole Count
Sets the number of PM motor poles.
4
(2 - 120)
Note:
When A1-02 = 5, 6 or 8 [PM OLVector, PM AOLVector or EZ Vector], the maximum value is 48.
These types of Auto-Tuning will automatically set this parameter to the value of [Number of Motor Poles]:
• PM Motor Parameter Settings
• PM Stationary Auto-Tuning
• PM Rotational Auto-Tuning
■ E5-05: PM Mot Resistance (Ohms/Phase)
No.
(Hex.)
Name Description
Default
(Range)
E5-05
(032D)
PM Mot Resistance (Ohms/
Phase)
Sets the resistance per phase of a PM motor. Set 50% of the line-to-line resistance.
0.100 Ω
(0.000 - 65.000 Ω)
PM motor Auto-Tuning automatically sets this parameter to the value of [PM Motor Stator Resistance].
Note:
Do not change the setting calculated by Auto-Tuning unless it is necessary.
■ E5-06: PM d-Axis Inductance (mH/Phase)
No.
(Hex.)
Name Description
Default
(Range)
E5-06
(032E)
PM d-Axis Inductance
(mH/Phase)
Sets the PM motor d-axis inductance.
1.00 mH
(0.00 - 300.00 mH)
PM motor Auto-Tuning automatically sets this parameter to the value of [PM Motor d-Axis Inductance].
Note:
Do not change the setting calculated by Auto-Tuning unless it is necessary.
■ E5-07: PM q-Axis Inductance (mH/Phase)
No.
(Hex.)
Name Description
Default
(Range)
E5-07
(032F)
PM q-Axis Inductance
(mH/Phase)
Sets the PM motor q-axis inductance.
1.00 mH
(0.00 - 600.00 mH)
PM motor Auto-Tuning automatically sets this parameter to the value of [PM Motor q-Axis Inductance].
Note:
Do not change the setting calculated by Auto-Tuning unless it is necessary.
■ E5-09: PM BackEMF Vpeak (mV/(rad/ s))
No.
(Hex.)
Name Description
Default
(Range)
E5-09
(0331)
PM BackEMF Vpeak (mV/
(rad/ s))
Sets the peak value of PM motor induced voltage.
0.0 mV/(rad/sec)
(0.0 - 2000.0 mV/(rad/s))
Set this parameter when you use an IPM motor (SSR1-Series).
PM motor Auto-Tuning automatically sets this parameter to the value of [Back-EMF Voltage Constant (Ke)].
When E5-01 = FFFF, only set E5-09 or E5-24 [PM BackEMF L-L Vrms (mV/rpm)] as the induced voltage
constant.
Note:
When you set this parameter, also set E5-24 = 0.0. The drive will detect oPE08 [Parameter Selection Error] in these conditions:
• E5-09 = 0.0 and E5-24 = 0.0
• E5-09 ≠ 0.0 and E5-24 ≠ 0.0
