Parameter List
11
11.8 F: OPTIONS
SIEPCYEUOQ2V01A Q2V Technical Manual 345
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-04
(03E8)
IP Address 4
Sets the fourth octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 to set the IP Address. Be sure to set a different IP
address for each drive on the network.
• Also set parameters F7-01 to F7-12.
20
(0 - 255)
560
F7-05
(03E9)
Subnet Mask 1
Sets the first octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
560
F7-06
(03EA)
Subnet Mask 2
Sets the second octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
560
F7-07
(03EB)
Subnet Mask 3
Sets the third octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
560
F7-08
(03EC)
Subnet Mask 4
Sets the fourth octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
0
(0 - 255)
560
F7-09
(03ED)
Gateway Addr 1
Sets the first octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
192
(0 - 255)
560
F7-10
(03EE)
Gateway Addr 2
Sets the second octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
168
(0 - 255)
560
F7-11
(03EF)
Gateway Addr 3
Sets the third octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
561
F7-12
(03F0)
Gateway Addr 4
Sets the fourth octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
561
F7-13
(03F1)
Addr Mode@Startup
Sets the method to set option card IP addresses.
0 : Static
1 : BOOTP
2 : DHCP
Note:
• The following setting values are available when using the PROFINET
communication option card (SI-EP3).
–0: Static
–2: DHCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [IP Address 1 to Gateway Addr
4] to set the IP Address. Be sure to set a different IP address for each drive on the
network.
2
(0 - 2)
561
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
0 : Half/Half
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
4 : Half/Full
5 : Auto/Half
6 : Auto/Full
7 : Full/Half
8 : Full/Auto
1
(0 - 8)
561
