Parameter Details
12
12.6 F: OPTIONS
SIEPCYEUOQ2V01A Q2V Technical Manual 561
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-11: Gateway Addr 3
No.
(Hex.)
Name Description
Default
(Range)
F7-11
(03EF)
Gateway Addr 3
Sets the third octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-12: Gateway Addr 4
No.
(Hex.)
Name Description
Default
(Range)
F7-12
(03F0)
Gateway Addr 4
Sets the fourth octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-13: Addr Mode@Startup
No.
(Hex.)
Name Description
Default
(Range)
F7-13
(03F1)
Addr Mode@Startup
Sets the method to set option card IP addresses.
2
(0 - 2)
0 : Static
1 : BOOTP
2 : DHCP
• The following setting values are available when using the PROFINET communication option card (SI-EP3).
– 0: Static
– 2: DHCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [IP Address 1 to Gateway Addr 4] to set the IP Address. Be
sure to set a different IP address for each drive on the network.
■ F7-14: Duplex Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
1
(0 - 8)
0 : Half/Half
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
Port 1 is set to “Half” and port 2 is set to “Auto”.
4 : Half/Full
Port 1 is set to “Half” and port 2 is set to “Full”.
5 : Auto/Half
Port 1 is set to “Auto” and port 2 is set to “Half”.
6 : Auto/Full
Port 1 is set to “Auto” and port 2 is set to “Full”.
7 : Full/Half
Port 1 is set to “Full” and port 2 is set to “Half”.
8 : Full/Auto
