12.6 F: OPTIONS
562 SIEPCYEUOQ2V01A Q2V Technical Manual
Port 1 is set to “Full” and port 2 is set to “Auto”.
■ F7-15: Comm. BaudRate
No.
(Hex.)
Name Description
Default
(Range)
F7-15
(03F3)
Comm. BaudRate
Sets the communications speed.
10
(10, 100 - 102)
10 : 10/10 Mbps
100 : 100/100 Mbps
101 : 10/100 Mbps
102 : 100/10 Mbps
Note:
Set this parameter when F7-14 = 0 or 2 [Duplex Mode Selection = Half/Half or Full/Full].
■ F7-16: Timeout Value
No.
(Hex.)
Name Description
Default
(Range)
F7-16
(03F4)
Timeout Value
Sets the detection time for a communications timeout.
0.0 s
(0.0 - 30.0 s)
Note:
Set this parameter to 0.0 to disable the connection timeout function.
■ F7-17: E/IP Speed Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-17
(03F5)
E/IP Speed Scale Factor
Sets the scaling factor for the speed monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-18: E/IP Current Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-18
(03F6)
E/IP Current Scale Factor
Sets the scaling factor for the output current monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-19: E/IP Torque Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-19
(03F7)
E/IP Torque Scale Factor
Sets the scaling factor for the torque monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-20: E/IP Power Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-20
(03F8)
E/IP Power Scale Factor
Sets the scaling factor for the power monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-21: E/IP Voltage Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-21
(03F9)
E/IP Voltage Scale Factor
Sets the scaling factor for the voltage monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
