Omron Q2V Series User Manual

11.20 Defaults by Drive Model and Duty Rating ND/HD
420 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
*1
Name Unit Default
- Drive Model - 4060
C6-01 ND/HD Duty Selection -
HD ND
0 1
o2-04 Drive KVA Selection Hex. 9F
E2-11
(E4-11, E5-02)
Motor Rated Power (kW) kW 22 30
E2-02
(E4-02)
Mot Rated Slip Hz 1.7 1.8
E2-03
(E4-03)
Mot No-Load Current A 9.2 10.9
E2-05
(E4-05)
Motor L-L Resistance Ω 0.316 0.269
E2-06
(E4-06)
Motor Leak Inductance % 23.5 20.7
E2-10
(E4-10)
Motor Iron Loss W 586 750
E5-01 PM Mot Code Selection - FFFF FFFF
L2-02 RideThrough Time@Power Loss s 2 2
L2-03 Min Baseblck Time s 1 1.1
L2-04 Powloss Ramp Time@recovery s 0.6 0.6
L2-05 UV Detection Lvl (Uv1) - 380 380
L3-02 StallP Level@Accel % 150 120
L3-06 StallP Level@Run % 150 120
L3-24 Acc@Rated Torque s 0.355 0.323
L8-02 Overheat Alm Level °C 115 115
L8-09 Ground Fault Selection - 1 1
n1-03 HuntPrev Time Constant ms 10 10
n3-02
HSB CurrLim Level
% 150 120
n5-02 Mot Inertia Acceleration Time s 0.355 0.323
*1 Parameters within parentheses are for motor 2.
