Omron Q2V Series User Manual

Parameter List
11
11.20 Defaults by Drive Model and Duty Rating ND/HD
SIEPCYEUOQ2V01A Q2V Technical Manual 419
No.
*1
Name Unit Default
- Drive Model - 4023 4031 4038 4044
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 9A 9C 9D 9E
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 7.5 11 11 15 15 18.5 18.5 22
E2-06
(E4-06)
Motor Leak
Inductance
% 15.5 19.6 19.6 17.2 17.2 20.1 20.1 23.5
E2-10
(E4-10)
Motor Iron
Loss
W 263 385 385 440 440 508 508 586
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 1 1 2 2 2 2 2 2
L2-03
Min Baseblck
Time
s 0.8 0.9 0.9 1 1 1 1 1
L2-04
Powloss
Ramp
Time@recov
ery
s 0.3 0.3 0.3 0.6 0.6 0.6 0.6 0.6
L2-05
UV Detection
Lvl (Uv1)
- 380 380 380 380 380 380 380 380
L3-02
StallP
Level@Accel
% 150 120 150 120 150 120 150 120
L3-06
StallP
Level@Run
% 150 120 150 120 150 120 150 120
L3-24
Acc@Rated
Torque
s 0.175 0.265 0.265 0.244 0.244 0.317 0.317 0.355
L8-02
Overheat Alm
Level
°C 120 120 120 120 120 120 125 125
L8-09
Ground Fault
Selection
- 0 0 1 1 1 1 1 1
n1-03
HuntPrev
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
% 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.175 0.265 0.265 0.244 0.244 0.317 0.317 0.355
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 4060
C6-01 ND/HD Duty Selection -
HD ND
0 1
o2-04 Drive KVA Selection Hex. 9F
E2-11
(E4-11, E5-02)
Motor Rated Power (kW) kW 22 30
b3-04 SpSrch V/F Gain % 100 100
b3-06 Speed Curr Lev1 for Estimation - 0.5 0.5
b3-08 Speed ACR PGain for Estimation - 0.5 0.5
b3-26 Dir. Determ. Level - 1000 1000
b8-03 eSave Filter Time s 0.5 0.5
b8-04 eSave Coef. Value - 103.58 92.54
C6-02 Carrier Frequency Selection - 3 7
E2-01
(E4-01)
Mot Rated Current (FLA) A 38.6 52.3
