Parameter List
11
11.20 Defaults by Drive Model and Duty Rating ND/HD
SIEPCYEUOQ2V01A Q2V Technical Manual 417
No.
*1
Name Unit Default
- Drive Model - 4001 4002 4004 4005
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 91 92 93 94
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 0.2 0.4 0.4 0.75 0.75 1.5 1.5 2.2
n3-02
HSB CurrLim
Level
% 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.178 0.178 0.178 0.142 0.142 0.166 0.166 0.145
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 4007 4009 4012 4018
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 95 96 97 99
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 2.2 3.0 3.0 3.7 4.0 5.5 5.5 7.5
b3-04
SpSrch V/F
Gain
% 100 100 100 100 100 100 100 100
b3-06
Speed Curr
Lev1 for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed ACR
PGain for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Dir. Determ.
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
eSave Filter
Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
eSave Coef.
Value
- 313.6 265.7 265.7 245.8 245.8 189.5 189.5 145.38
C6-02
Carrier
Frequency
Selection
- 3 7 3 7 3 7 3 7
E2-01
(E4-01)
Mot Rated
Current (FLA)
A 4.2 5.7 5.7 7 7 9.8 9.8 13.3
E2-02
(E4-02)
Mot Rated
Slip
Hz 3 2.7 2.7 2.7 2.7 1.5 1.5 1.3
E2-03
(E4-03)
Mot No-Load
Current
A 1.5 1.9 1.9 2.3 2.3 2.6 2.6 4
E2-05
(E4-05)
Motor L-L
Resistance
Ω 6.495 4.36 4.36 3.333 3.333 1.595 1.595 1.152
E2-06
(E4-06)
Motor Leak
Inductance
% 18.7 19 19 19.3 19.3 18.2 18.2 15.5
E2-10
(E4-10)
Motor Iron
Loss
W 77 105 105 130 130 193 193 263
E5-01
PM Mot Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
RideThrough
Time@Power
Loss
s 0.5 0.5 0.5 0.5 0.5 0.5 0.8 0.8
L2-03
Min Baseblck
Time
s 0.5 0.5 0.5 0.6 0.6 0.7 0.7 0.8
L2-04
Powloss
Ramp
Time@recov
ery
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
