11.20 Defaults by Drive Model and Duty Rating ND/HD
418 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
*1
Name Unit Default
- Drive Model - 4007 4009 4012 4018
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 95 96 97 99
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 2.2 3.0 3.0 3.7 4.0 5.5 5.5 7.5
L2-05
UV Detection
Lvl (Uv1)
- 380 380 380 380 380 380 380 380
L3-02
StallP
Level@Accel
% 150 120 150 120 150 120 150 120
L3-06
StallP
Level@Run
% 150 120 150 120 150 120 150 120
L3-24
Acc@Rated
Torque
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
L8-02
Overheat Alm
Level
°C 90 90 115 115 110 110 120 120
L8-09
Ground Fault
Selection
- 0 0 0 0 0 0 0 0
n1-03
HuntPrev
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB CurrLim
Level
% 150 120 150 120 150 120 150 120
n5-02
Mot Inertia
Acceleration
Time
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 4023 4031 4038 4044
C6-01
ND/HD Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive KVA
Selection
Hex. 9A 9C 9D 9E
E2-11
(E4-11, E5-
02)
Motor Rated
Power (kW)
kW 7.5 11 11 15 15 18.5 18.5 22
b3-04
SpSrch V/F
Gain
% 100 100 100 100 100 100 100 100
b3-06
Speed Curr
Lev1 for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed ACR
PGain for
Estimation
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Dir. Determ.
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
eSave Filter
Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
eSave Coef.
Value
- 145.38 140.88 140.88 126.26 126.26 115.74 115.74 103.58
C6-02
Carrier
Frequency
Selection
- 3 7 3 7 3 7 3 7
E2-01
(E4-01)
Mot Rated
Current (FLA)
A 13.3 19.9 19.9 26.5 26.5 32.9 32.9 38.6
E2-02
(E4-02)
Mot Rated
Slip
Hz 1.3 1.7 1.7 1.6 1.6 1.67 1.67 1.7
E2-03
(E4-03)
Mot No-Load
Current
A 4 5.6 5.6 7.6 7.6 7.8 7.8 9.2
E2-05
(E4-05)
Motor L-L
Resistance
Ω 1.152 0.922 0.922 0.55 0.55 0.403 0.403 0.316
