3 Operation
3 - 34
High-function General-purpose Inverter RX2 Series User’s Manual
You can change the content of display on the LCD operator according to your purpose.
To know which parameters are changed, you can check by setting [UA-10] to 03.
If you do not want to display parameters for functions not in use, you can reduce them by setting
[UA-10] to 01.
I you are not using the input terminal function [SET] for switching to the second setting, by setting
[UA-21] to 00, you can reduce a great number of displayed items.
I you are not using option unit, by setting [UA-22] to 00, you can reduce indications for option unit.
3-8-2 Limiting Displayed Parameters
Related Parameter
Item Parameter Data Description
Display restriction
selection
[UA-10] 00 All parameters are displayed.
01 Parameters are displayed by function. Disabled functions are
not displayed with some exceptions.
02 Display is performed in accordance with the settings config-
ured by the user. Parameters set to [UA-31] to [UA-62] are dis-
played with some exceptions.
03 Parameters that have been changed from the factory default
settings and some other parameters are displayed.
04 Monitor parameters and some other parameters are dis-
played.
2nd-motor parameter
display selection
[UA-21] 00 Hides parameters of second setting [**2**].
01 Displays parameters of second setting [**2**].
Option parameter dis-
play selection
[UA-22] 00 Hides parameters that start with o.
01 Displays parameters that start with o.
User parameter
selection
[UA-31] to
[UA-62]
no No assignment
***** Choose the code you want to display.
(all codes are subjected)
