Omron RX2 Series User Manual

11 Options
11 - 48
High-function General-purpose Inverter RX2 Series User’s Manual
Precautions for Correct UsePrecautions for Correct Use
• Wind the phase R/S/T wire in the same direction.
• This noise filter can be used in the same manner on both the input and output side of the
inverter.
11-9-3 Connection Example
R
S
T
M
Motor
Power
supply
Install them as
close as possible.
Inverter
U/T1
V/T2
W/T3
S/L2
T/L3
R/L1
