5 Monitor
5 - 4
High-function General-purpose Inverter RX2 Series User’s Manual
Frequency command after calculation [dA-04] monitors the state of command which is input ultimately
at the moment.
As for the Main Speed reference monitor [FA-01], frequency command setting value can be changed by
using UP/DOWN keys on the monitor, if the Main speed input source selection, 1st-motor [AA101] is set
to 07 (Parameter setting).
As for the Sub Speed reference monitor [FA-02], frequency command setting value can be changed by
using UP/DOWN keys on the monitor, if the Sub frequency input source selection, 1st-motor [AA102] is
set to 07 (Parameter setting).
Precautions for Correct Use
• If the frequency command monitor does not change when frequency command is changed, a
command destination not intended by the frequency command may have taken a priority.
• The frequency command is influenced by the following functions:
• Main speed input source selection, 1st-motor [AA101]
• Sub frequency input source selection, 1st-motor [AA102]
• Jogging command [JG]
• Multi-speed command [CF/SF]
• Operation switching [SCHG]
• Calculation symbol selection for Speed reference, 1st-motor [AA105]
• Forced operation [F-OP]
• Addition [ADD]
•See 6-4 Frequency Command Settings on page 6-25 for details.
 Parameter
5-1-2 Frequency Command Monitor
Item Parameter Data Description
Frequency com-
mand
[dA-04] -590.00 to 590.00 (Hz)
Displays frequency command. Displays
a result of function such as jogging, multi
speed, and forced operation [F-OP].
Main Speed refer-
ence monitor
[FA-01] 0.00 to 590.00 (Hz)
Displays the command frequency
selected for the main speed input source
selection, 1st-motor [AA101].
Sub Speed refer-
ence monitor
[FA-02]
Monitor: 0.00 to 590.00 (Hz)
Setting: -590.00 to 590.00 (Hz)
Displays the command frequency
selected for the Sub frequency input
source selection, 1st-motor [AA102].
