Omron RX2 Series User Manual

8 - 181
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-11 Output Terminal Function
8
8-11-5 Analog Output Terminal Switch Settings
With Analog output terminals Ao1 and Ao2, you can select voltage output or current output by operating
Switches SW3 and SW4 on the substrate.
Precautions for Correct Use
• In the switch setting on the substrate during factory setting, [A01] is output voltage; [A02] is
output current.
• Operate the switches on the substrate while the inverter power supply is turned off.
• When [Cd-10]=01 is set, [FM], [Ao1], and [Ao2] respectively perform outputs in accordance
with values of [Cd-15], [Cd-25], and [Cd-35].
 Parameter
8-11-5 Analog Output Terminal Switch Settings
Item Parameter Data Description
Default
data
[Ao1] monitor output
selection
[Cd-04]
Parameter
number for
8-11-4 Analog
Output Termi-
nal Adjustment
on page 8-178.
Sets a parameter number.
[dA-01]
[Ao2] monitor output
selection
[Cd-05] [dA-01]
Analog monitor adjust
mode enable
[Cd-10]
00 Invalid.
00
01
Valid. Outputs to terminals output levels in
the adjustment mode.
Filter time constant of
[Ao1] monitor
[Cd-21] 1 to 500[ms] Filters and outputs the selected data. 100
[Ao1] Data type
selection
[Cd-22]
00 Outputs the absolute value of data.
00
01 Outputs data with a symbol as is.
[Ao1] monitor bias
adjustment
[Cd-23]
-100.0 to
100.0[%]
Biases data to adjust Point 0 of data. 0.0
[Ao1] monitor gain
adjustment
[Cd-24]
-1000.0 to
1000.0[%]
Apply a gain to data to adjust an inclination
in data.
100.0
Output level setting at
[Ao1] monitor adjust
mode
[Cd-25]
-100.0 to
100.0[%]
Sets output in the adjustment mode. It
selects the maximum output (at 100.0%),
the minimum output (at 0.0%) ([Cd-22]=00),
or the minimum output (at -100.0%)
([Cd-22]=01).
100.0
Filter time constant of
[Ao2] monitor
[Cd-31] 1 to 500[ms] Filters and outputs the selected data. 100
[Ao2] Data type
selection
[Cd-32]
00 Outputs the absolute value of data.
0
01 Outputs data with a symbol as is.
[Ao2] monitor bias
adjustment
[Cd-33]
-100.0 to
100.0[%]
Biases data to adjust Point 0 of data. 20.0
[Ao2] monitor gain
adjustment
[Cd-34]
-1000.0 to
1000.0[%]
Apply a gain to data to adjust an inclination
in data.
80.0
Output level setting at
[Ao2] monitor adjust
mode
[Cd-35]
-100.0 to
100.0[%]
Sets output in the adjustment mode. It
selects the maximum output (at 100.0%),
the minimum output (at 0.0%) ([Cd-32]=00),
or the minimum output (at -100.0%)
([Cd-32]=01).
100.0
