8 Applied Settings
8 - 180
High-function General-purpose Inverter RX2 Series User’s Manual
db-44
PID1 feedback data monitor
-100.00 to 100.00(%)
*1
Outputting is possible with (±).
db-50 PID1 output monitor -100.00 to 100.00(%) Outputting is possible with (±).
db-51 PID1 deviation monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-52 PID1 deviation 1 monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-53 PID1 deviation 2 monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-54 PID1 deviation 3 monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-55 PID2 output monitor -100.00 to 100.00(%) Outputting is possible with (±).
db-56 PID2 deviation monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-57 PID3 output monitor -100.00 to 100.00(%) Outputting is possible with (±).
db-58 PID3 deviation monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-59 PID4 output monitor -100.00 to 100.00(%) Outputting is possible with (±).
db-60 PID4 deviation monitor -200.00 to 200.00(%) Outputting is possible with (±).
db-64 PID feedforward monitor 0.00 to 100.00(%)
dC-15 Cooling fin temperature monitor -20.0 to 200.0(°C)
*1. Data range varies depending on the data from [AH-04] to [AH-06].
*2. Data range varies depending on the data from [AJ-04] to [AJ-06].
*3. Data range varies depending on the data from [AJ-24] to [AJ-26].
*4. Data range varies depending on the data from [AJ-44] to [AJ-46].
Code Name
Output scale range
(Corresponding to 0 to 10 V /
0 to 20 mA / 0 to 100%)
Remarks
FA-01 Main speed command monitor 0.00 to 590.00(Hz)
FA-02
Auxiliary speed command mon-
itor
0.00 to 590.00(Hz)
FA-15 Torque command monitor
Motor rated torque ×
(-500.0 to 500.0(%))
*1
*1. To calculate the motor rated torque (100%), use the following formula.
Motor rated torque = 79.58 × Motor capacity × Number of poles/Base frequency
Example: Motor rated torque = 79.58 × 5.5 (kW) × 4 (P)/50 (Hz) ≈ 35 Nm
Outputting is possible with (±).
FA-16 Torque bias command monitor
Motor rated torque ×
(-500.0 to 500.0(%))
*1
Outputting is possible with (±).
FA-30 PID1 target value 1
0.00 to 100.00(%)
*2
*2. Data range varies depending on the data from [AH-04] to [AH-06].
FA-32 PID1 target value 2
0.00 to 100.00(%)
*2
FA-34 PID1 target value 3
0.00 to 100.00(%)
*2
FA-36 PID2 target value
0.00 to 100.00(%)
*3
*3. Data range varies depending on the data from [AJ-04] to [AJ-06].
FA-38 PID3 target value
0.00 to 100.00(%)
*4
*4. Data range varies depending on the data from [AJ-24] to [AJ-26].
FA-40 PID4 target value
0.00 to 100.00(%)
*5
*5. Data range varies depending on the data from [AJ-44] to [AJ-46].
Code Name
Output scale range
(Corresponding to 0 to 10 V /
0 to 20 mA / 0 to 100%)
Remarks
