Omron RX2 Series User Manual

11 - 51
11 Options
High-function General-purpose Inverter RX2 Series User’s Manual
11-10 EMC Noise Filter
(Model: 3G3AX-EFI)
11
11-10-2 External Dimensions
11-10-2 External Dimensions
3G3AX-EFI41/EFI42
Model Case, enclosure rating Screw size Wire size Weight [kg]
3G3AX-EFI41
Plastic, IP00
M4
1.25 mm
2
, 2 mm
2
0.7
3G3AX-EFI42
2 mm
2
0.7
3G3AX-EFI43
M5
2 mm
2
, 3.5 mm
2
1.0
3G3AX-EFI44
5.5 mm
2
1.3
3G3AX-EFI45
8 mm
2
1.4
3G3AX-EFI46
Metal, IP00
M6
14 mm
2
2.9
3G3AX-EFI47
14 mm
2
3.0
3G3AX-EFI48
22 mm
2
3.6
3G3AX-EFI49
M8
30 mm
2
, 38 mm
2
4.3
3G3AX-EFI4A
38 mm
2
, 60 mm
2
9.0
3G3AX-EFI4B M10
100 mm
2
or 38 mm
2
, 2 wires parallel
16.0
74
56
144
73
(15)
130
(95)
5
M4
11
L3’ L2’
L1’
L3 L2 L1
Ground
terminal φ5
