5-8 Power Monitor
5
5-8-1 Input Power Monitor
5-8 Power Monitor
The input power monitor [dA-30] displays the current power input to the inverter.
The integrated input power monitor [dA-32] displays the integrated data of the power input to the
inverter.
Additional Information
• Display gain for Accumulation input power monitor [UA-13] mode, the displayed contents can
be converted with gain.
[dA-32]= “Calculated input power value (kWh)”/[UA-13]
([UA-13] can be set from 1. to 1000. by an unit.)
• Accumulation input power monitor clear [UA-12] to “01” and then determining it, you can
clear an integrated input power value.
• Also, if 039 [KHC] (clearing of integrated input power) has been assigned to one of the input
terminals, integrated input power value can be cleared via that terminal.
 Parameter
5-8-1 Input Power Monitor
Item Parameter Data Description
Input power monitor [dA-30] 0.00 to 600.00 (kW)
Displays the input power. Changes
according to input power factors.
Integrated input power
monitor
[dA-32] 0.0 to 100000.0 (kWh)
Displays the integrated value of input
power. Changes according to input
power factors.
Accumulation input
power monitor clear
[UA-12]
00 Disable
01 Clear
Display gain for
Accumulation input
power monitor
[UA-13] 1 to 1000
Displays a value obtained by multiply-
ing by gain.
Input terminal function
[CA-01] to
[CA-11]
039
[KHC] Clearing of integrated input
power terminal
