Omron RX2 Series - Switching of Acceleration or Deceleration Time with Multi-Speed Step

6 - 61
6 Basic Parameter Settings
High-function General-purpose Inverter RX2 Series User’s Manual
6-7 Acceleration/Deceleration Settings
6
6-7-3 Switching of Acceleration or Deceleration Time with Multi-Speed Step
Setting up this function allows the acceleration or deceleration time to be changed in response to the
multi-speed command.
Also this function changes several settings of acceleration/deceleration times while the motor is being
accelerated to reach the fixed frequency.
Precautions for Correct Use
• When using the input terminal function to switch the multiple speeds, operation should be
performed by assigning 003 [CF1] to 006 [CF4] or 007 [SF1] to 013 [SF7] to any of [CA-01] to
[CA-11].
• When [AC-02] Acceleration/ Deceleration Selection is 01, the 2-stage acceleration or decel-
eration function is disabled.
 Parameter
6-7-3 Switching of Acceleration or Deceleration Time with Multi-Speed
Step
Item Parameters Data Description
Default
data
Acceleration/ Deceler-
ation Selection
[AC-02]
00
The acceleration or deceleration time fol-
lows [AC120]/[AC122] or
[AC124]/[AC126] (when 2-stage acceler-
ation or deceleration function is
enabled).
00
01
The acceleration or deceleration time will
be switched in accordance with the
multi-speed command.
Multi-speed command [Ab-11] to [Ab-25]
0.00 to
590.00(Hz)
Set the multi-speed command with 1st
speed [Ab-11] to 15th speed [Ab-25].
0.00
Acceleration time
set-up for the
multi-speed 1st to 15th
speeds
[AC-30], [AC-34],
[AC-38], [AC-42],
[AC-46], [AC-50],
[AC-54], [AC-58],
[AC-62], [AC-66],
[AC-70], [AC-74],
[AC-78], [AC-82],
[AC-86]
0.00 to
3600.00(s)
Set an acceleration time ranging from 0
Hz to the maximum frequency for each
of the multi-speed commands.
0.00
Deceleration time
set-up for the
multi-speed 1st to 15th
speeds
[AC-32], [AC-36],
[AC-40], [AC-44],
[AC-48], [AC-52],
[AC-56], [AC-60],
[AC-64], [AC-68],
[AC-72], [AC-76],
[AC-80], [AC-84],
[AC-88]
0.00 to
3600.00(s)
Set a deceleration time ranging from the
maximum frequency to 0 Hz for each of
the multi-speed commands.
0.00
Multispeed operation
selection
[Ab-03]
00
Corresponding to 16-speed binary oper-
ation. 003[CF1] to 006[CF4]
00
01
Corresponding to 8-speed bit operation.
007[SF1] to 013[SF7]
Input terminal function
selection
[CA-01] to [CA-11]
003 to 006/
007 to 013
Implementing the multi-speed command.
003[CF1] to 006[CF4]/007[SF1] to
013[SF7]
-
