Appendices B STO Function
B - 2
High-function General-purpose Inverter RX2 Series User’s Manual
B-1 Overview of STO Function
3G3RX2-series is an inverter built- in STO (Safe torque off) function defined in IEC 61800-5-2.
STO Function is used to shut off the motor current with input signals from a safety controller and to stop
the motor.
This function is equivalent to stop category 0 defined in EN/IEC60204-1.
Precautions for Correct Use
Design
The 3G3RX2-series does not feature a function to retain STO status. When STO input is
reset, the inverter goes into a state of operation enabled and starts the operation when oper-
ation command is input.
Design a system to disallow hazardous status when STO input is reset with consideration
mentioned earlier.
In default data set before shipment, STO function is disabled by short-circuit wires.
Installment
Qualified engineers that have enough knowledge about function/safety shall install the
inverter.
Wiring
The 3G3RX2-series does not feature a function to carry out diagnosis of STO input signals.
Be sure to design a system that can provide 2 inputs normally. As necessary, carry out error
diagnosis for input path with EDM signal output.
STO input signals via two channels outside the inverter shall be separated and protected
appropriately. No interruption shall be made on each signal.
The cable length for signals connected to ST1/ST2 or EDM terminal shall be each 20m or
less.
Test Run
Be sure to conduct a test run to verify safety system and check the validity. The safety sys-
tem without this check shall not be regarded as “Safe”.
Maintenance
STO function does not cut off the power supplies for the inverter main circuit and its periph-
eral circuit. When you make maintenance, be sure to separate a safety system away from
the main power supply or devices like permanent magnet motors or capacitors to which volt-
age is likely supplied.
Be sure to carry out the followings before the maintenance:
Wait for ten minutes or more
*1
or fifteen minutes or more
*2
after cutting off power supply.
Check that voltage between PN terminals is 45V or less after a charge LED goes out.
Be sure to conduct periodic function test every year.
Others
Never modify the inverter. The modified inverter is out of conformity with criteria and product
guarantee.
*1 In the case of 3G3RX2-A2004 to -A2220 / -A4007 to -A4220
*2 In the case of 3G3RX2-A2300 to -A2550/ -A4300 to -A4550/ -B4750/ -B4900/ -B411K/
-B413K
