High-function General-purpose Inverter RX2 Series User’s Manual
3-9 Display Fixation Function
3
3-9 Display Fixation Function
You can fix the display by DISP terminal.
When the [DISP] function of the input terminal function is on, display of the LCD operator is fixed on the
monitor screen (the home screen selected in LCD operator).
When the [DISP] function of the input terminal function is on, keys other than the RUN key and
STOP/RESET keys are disabled.
To disable the RUN key, set [AA111] to a value other than 02.
The following shows operations when the [DISP] terminal is on.
• When STOP key selection [AA-13] is 01, even if [AA111] is other than 02, you can stop the inverter or
reset inverter trip by using the STOP/RESET key.
• When STOP key selection [AA-13] is 02, even if [AA111] is other than 02, you can reset inverter trip
by using the STOP/RESET key.
• When STOP key selection [AA-13] is 00, if [AA111] is other than 02, the STOP/RESET key is also
disabled, thus disabling all keys.
Parameter
Item Parameter Data Description
Selecting the input
terminal
[CA-01] to
[CA-11]
102 [DISP]: Used when the screen fixation function is used on ter-
minals.
Operation com-
mand selection
[AA111] 00 [FW]/[RV] terminals
01 3 wire
02 RUN key on the LCD Operator
03 RS485 setting
04 Option 1
05 Option 2
06 Option 3
STOP key
selection
[AA-13] 00 Disable
01 Enable
02 Enable only reset
