9 - 23
9 Communications Functions
High-function General-purpose Inverter RX2 Series User’s Manual
9-5 Modbus Communication Register Number List
9
9-5-2 Group d Register List
Precautions for Correct UsePrecautions for Correct Use
• The “Register No.” in the table header shows the register number used inside the inverter.
• The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
9-5-2 Group d Register List
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
2711h 2710h Output frequency monitor dA-01 R 0 to 59000 0.01(Hz)
2712h 2711h Output current monitor dA-02 R 0 to 65535 0.01(A)
2713h 2712h Operation direction monitor dA-03 R
00: o (Stopped)
01: d (0Hz output)
02: F (Normal rotation in process)
03: r (Reverse rotation in pro-
cess)
-
2714h 2713h
Frequency command after
calculation
dA-04
(HIGH)
R
-59000 to 59000 0.01(Hz)
2715h 2714h
dA-05
(LOW)
R
2716h 2715h
Output frequency conver-
sion monitor
dA-06
(HIGH)
R
0 to 5900000 0.01
2717h 2716h
dA-07
(LOW)
R
2718h 2717h
Speed detection value moni-
tor
dA-08
(HIGH)
R
-59000 to 59000 0.01(Hz)
2719h 2718h
dA-09
(LOW)
R
271Ch 2719h
Output frequency monitor
(with sign)
dA-12
(HIGH)
R
-59000 to 59000 0.01(Hz)
271Dh 271Ch
dA-13
(LOW)
R
271Eh 271Dh
Frequency upper limit moni-
tor
dA-14 R 0 to 59000 0.01(Hz)
271Fh 271Eh
Torque command monitor
after calculation
dA-15 R -10000 to 10000 0.1(%)
2720h 271Fh Torque limit monitor dA-16 R 0 to 5000 0.1(%)
2721h 2720h Output torque monitor dA-17 R -10000 to 10000 0.1(%)
2722h 2721h Output voltage monitor dA-18 R 0 to 8000 0.1(V)
2724h 2723h
Current position monitor
dA-20
(HIGH)
R
In the case of AA121=10 and
AA123=03, data range
-2147483648 to 2147483647.
In the case of the condition men-
tioned above, data range
-536870912 to 536870911
1(pls)
2725h 2724h
dA-21
(LOW)
R
272Ah 2729h
Pulse train position deviation
monitor
dA-26
(HIGH)
R
-2147483647 to 2147483647 1(pls)
272Bh 272Ah
dA-27
(LOW)
R
