9 Communications Functions
9 - 42
High-function General-purpose Inverter RX2 Series User’s Manual
Precautions for Correct UsePrecautions for Correct Use
The “Register No.” in the table header shows the register number used inside the inverter.
The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
9-5-4 Group A Register List
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
2EE1h 2EF0h
Main speed input source
selection, 1st-motor
AA101 R/W
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
14: Program function
15: PID calculation
16: (Reserved)
-
2EE2h 2EE1h
Sub frequency input source
selection, 1st-motor
AA102 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
14: Program function
15: PID calculation
16: (Reserved)
-
2EE4h 2EE3h Sub speed setting, 1st-motor AA104 R/W 0 to 59000 0.01(Hz)
2EE5h 2EE4h
Calculation symbol selection
for Speed reference,
1st-motor
AA105 R/W
00: Disabled
01: Addition
02: Subtraction
03: Multiplication
-
2EE6h 2EE5h
Add frequency setting,
1st-motor
AA106
(HIGH)
R/W
-59000 to 59000 0.01(Hz)
2EE7h 2EE6h
AA107
(LOW)
R/W
