11 Options
11 - 54
High-function General-purpose Inverter RX2 Series User’s Manual
11-10-3 Connection Example
L1
L1'
L2'
L3'
L2
L3
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
M
(Power supply)
EMC
noise filter
Molded case
circuit breaker
Motor
Inverter
